Laying Out

With your boards checked for square, lay out the groove across the grain, somewhere not too close to the ends. Begin by making a pencil line with a square, and then bring in the other board (shelf piece) right up against your square. Mark along the other side of this piece with a pencil. These are now the approximate positions of the walls of the recess.

Square a pencil line across the width of your board
Square a pencil line across the width of your board
Place the second piece against the square and trace a pencil line on the other side to mark the width
Place the second piece against the square and trace a pencil line on the other side to mark the width
Carry the lines over onto both edges with a square, but only part way
Carry the lines over onto both edges with a square, but only part way
